14.1 T Small Excavator SANY SY155H

Small Tonnage Crawler Excavator

SY155H is a compact and versatile machine incorporated with the ability to rotate at the base while remaining within the width of its track called "ZERO TAIL SWING" and hence easily work at tight and compact space.

● Brand Name: SANY

● Engine Model: Isuzu 4JJ1

● Engine Power: 84 kW

● Bucket Load: 0.65 m³

● Operating Weight: 14.1 T

● Classification: Small Crawler Excavator

SY155H has compact design with ability to rotate the base of upper frame while remaining within width of its track (ZTS), thereby highly versatile to operate within tight, confined spaces as well as in close proximity to walls, foundations & other obstacles in machine's working range.
Specifications Benefits & Features Video
Model SY80U SY65W SY75C SY135C SY155H
Arm Digging Force 40.5KN 33KN 38KN 66KN 75KN
Bucket Capacity 0.28m³ 0.21m³ 0.28m³ 0.6m³ 0.58m³
Bucket Digging Force 72.7KN 45KN 56KN 92.7KN 102.3KN
Carrier Wheel on Each Side 1   1 1
Engine Displacement 3.318L 2.615L 2.179L 2.999L 5.193L
Engine Model Top brand 4TNV98CT Top brand V2607-DI Top brand 4LE2 Top brand 4JJ1X 4HK1X
Engine Power 53.7kW 45.4kW 43kW 73kW 120kW
Fuel Tank 100L 130L 150L 240L 240L
Hydraulic Tank 120L 85L 120L 150L 150L
Operating Weight 8.8T 5.92T 7.28T 13.5T 13.5T
Radiator 12L 5.6L 6.5L 10L 10L
Standard Boom 3.52m 3m 3.72m 4.6m 4.6m
Standard Stick 2.05m 1.55m 1.62m 2.5m 2.1m
Thrust Wheel on Each Side 5   5 7

sany excavator

14.1 T Small Excavator SANY SY155H Highlights

The engine output power of SY155H 14.1 ton excavator is 84kW with increased hydraulic power and improved fuel efficiency. The 14.1 ton excavator adopts the customized engine with four cylinder, four-stroke direct-injection turbocharger, and providing strong operating power for the machine. The engine is designed with four working modes. The working mode can be changed on the monitor, which can maximize the operating efficiency and reduce the fuel consumption.

SY155H OPTIONAL EQUIPMENT

  1. - Hammer pipe lines
  2. - Two-way lines (Attachement has two functions)
  3. - Working flash lamp
  4. - Travel acoustic alarm
  5. - Rubber Track
  6. - Thick undercover
  7. - Zero-swing or short tail
  8. - Battery main switch
  9. - Engine emergency cut off
  10. - Travel Motor: imported
